Application:Outdoor
Type:LED
Color:1R1G1B
Life span:100000hours
Cabinet size:500x500mm/500x1000mm
Scan mode:1/16scan
Pixel density:65536dots/m2
Control system:Synchronous control system

Description

LED Display Features:

1.Seamless splicing, super wide viewing angle, High brightness & color consistency

2.It delivers an image which is super subtle and without getting tired after a longtime watching

3.Super high refresh rate, high frame frequency, no ghosting &twisting or smear

4.Front serviceable module allows easy maintenance, saving time & space

5.16 Bit grey grade processing, the color transition will be more natural


    2. Tuosheng’s high-precision full-color LED display technology will tailor high-precision video walls and image walls for various conference rooms, auditoriums, cinemas, banquet halls, government and enterprise lobbies, and high-end offices. Let users create an unattended new communication platform for customers and employees on their core publicity positions, and use the latest technological means to allow audiences to obtain more, higher and deeper value-added exchanges whether intentionally or unintentionally. .

3. Wonderful presentation, realistic picture
      Low brightness and high gray: 16bit low brightness and high gray, high gray level lossless technology is still maintained under 200nits, the details of the picture are clearly visible;
      high refresh rate: 3840HZ, no flicker on the screen;
      wide color gamut: support 2500k to 9500k color temperature wide-range adjustment, rich colors;
      point-by-point correction: ensure high color consistency and uniformity of the entire screen;




  4. Rich multimedia interfaces
      support AV, VGA, DVI, HDMI, DP, SDI and other mainstream multimedia interfaces;
      receive network streams media playback.

Cases

Australia-April 2020

Australia-April 2020

USA-May 2019

USA-May 2019

USA- June 2021

USA- June 2021

New Gabon- August 2020

New Gabon- August 2020

USA- February 2022

USA- February 2022

Malaysia- April 2022

Malaysia -April 2022

Parameters

Technical Parameters

Product Name

P1.953

P2.604

P2.976

P3.91

P4.81

Use Place

Indoor / Outdoor

Pixel Composition

1R1G1B

LED Encapsulation

SMD1515/SMD2020/SMD1921

Density ofpixel/(dots/m2)

262144dots/m2

147474dots/m2

112896dots/m2

65410dots/m2

43222dots/m2

Size of Module(mm*mm)

250mm*250mm

Drive Method

1/32s

1/32s

1/28s,1/21s

1/16s

1/16s

Best Viewing Angle(Horizontal/Vertical)

H:>160°Optional,V:>120Optional

Refresh Rate

>3840HZ

White BalanceBrightness

Indoor 1000cd/m/Outdoor 4000cd/m

Cabinet Size

500*500*85mm/500*1000*85mm

Cabiner Weight

7kg/11kg

Blind Spot Rate

<0.000001

Grey Scale

14 bits per color
